The 5m Ultrasonic + IR Kiosk Proximity Sensor is a compact, low-voltage IR + ultrasonic sensor designed for kiosk and people-detection applications. By combining optical proximity sensing with ultrasonic ranging, it offers dependable object detection from the front face out to 5 m, with 1 mm resolution and range measurements from 30 cm to 5 m.

Each sensor auto-calibrates for temperature, supply voltage, and target characteristics, delivering stable readings even in acoustically noisy indoor environments. USB and QWIIC-I2C variants simplify connection to computers and embedded systems while keeping the sensor dimensions under two cubic inches for easy mounting.

The Flood Level Ultrasonic Sensor provides highly accurate non-contact measurement for flood detection and water level monitoring. With 1 mm resolution and models available in 5 m and 10 m max ranges, this sensor is designed for reliable operation in stormwater, municipal, and environmental monitoring applications.

Near-field handling is built in: targets closer than minimum range are reported as minimum range for predictable readings (300mm on 5m models and 500mm on 10m models.)

(Optional at purchase: 4–20 mA; requires 9–36 VDC and replaces standard outputs).

Ultrasonic snow depth sensor for weather stations and environmental monitoring. 5 m maximum range, 1 mm resolution, and internal temperature compensation.

Standard (~6 Hz Update Rate) or condensation self-cleaning (~0.5 Hz Update Rate) variants. RS232 or TTL serial plus analog voltage and pulse-width outputs.

Near-field handling is built in: targets closer than 500 mm report as 500 mm for predictable readings.

Ultrasonic vehicle detection sensor for drive-thru lanes, gates, and parking garages. 5 m maximum range, 1 cm resolution, and ~250 ms between readings (~4 Hz), plus a preset 1.5 m proximity zone.

Near-field handling is built in: objects closer than 50 cm are reported as 50 cm for predictable behavior.

Interface is selected at purchase: Micro USB, TTL, or RS232.

MaxLidar™ MB8000: Precision LiDAR, 25m range, ±6 cm accuracy, 1kHz refresh rate, auto dust cleaning, IP5X-rated, Class 1 safe laser, industrial-grade, 3° FoV, low-power, UART/I2C interfaces.

MB7900 Sensor to 4-20mA Signal Converter

The MB7900 is an optional add-on for most WR and TankSensor models, enabling seamless integration with systems that require a 4-20mA output. This converter provides a 4-20mA signal through an M12 (8-pin) connection, available in both male and female connector versions, or via flying leads.

With the MB7900, there’s no need for third-party adapters, daughter boards, or additional workarounds to achieve 4-20mA compatibility—everything is built into the solution.

Note: This is not a standalone product. It must be selected as a configurable option for compatible sensors. Selecting "4-20mA" under output will automatically add the MB7900 Sensor to 4-20mA Signal Converter to the sensor's build.

The MB7940 EZ Mounting Hardware Kit is for use with our EZ sensors without housing options. The included hardware gives customers easy access for through-hole mounting.

*Sizes in the kit may vary depending on the material availability. If you have any questions please contact sensors@maxbotix.com*

The kit consists of:

4qty M3 x 6 Screws
4qty M3 Nuts
2qty M3 x 6 + 6 Male/Female Standoffs
2qty M3 x 8 + 6 Male/Female Standoffs (Current Stock Low)
2qty M3 x 10 + 6 Male/Female Standoffs
2qty M3 x 8 Female/Female Standoffs (Current Stock Low)
2qty M3 x 10 Female/Female Standoffs

*Sensors sold separately.

NEW! This ultrasonic tank level sensor features a 1mm resolution with a minimum range of 300mm and a 16.5-meter maximum range and operates from 5.5V to 40V.  The sensor has the following outputs: RS232 & TTL Serial, analog voltage, analog envelope.

NEW! This ultrasonic tank level sensor features a 1mm resolution with a minimum range of 300mm and a 16.5-meter maximum range and operates from 2.5V to 5V.  The sensor has the following outputs: RS232 & TTL Serial, analog voltage, analog envelope.

MB7851 is a weather-resistant ultrasonic tank-level sensor with 1 mm resolution, 5 m max range, and ~2 Hz read rate. Output is selectable by wiring—RS232 or TTL serial, scaled analog voltage, or analog envelope; supply 3.0–5.5 VDC

Near-field handling is built in: targets closer than 50 mm are reported as 50 mm for predictable readings.

(Optional at purchase: 4–20 mA; requires 9–36 VDC and replaces standard outputs).

Ranges from 20cm up to 765cm* with a 10Hz read rate. Pulse-width, analog voltage, and RS232 serial. Reports range to closest target. Uses a stability filter.

This ultrasonic tank level sensor features a 1cm resolution with a 5-cm minimum range and a 5-meter maximum range.  The sensor has the following outputs: RS232 & TTL Serial, analog voltage, analog envelope.

Ranges from 500mm to 5000mm with a 6Hz read rate. Pulse-width, analog voltage, and TTL serial. Reports range to closest target. Uses filtering to prevent rapid changes in readings. Filter resets at 2% window.

Ranges from 500mm to 5000mm with a 6Hz read rate. Pulse-width, analog voltage, and RS232 serial. Reports range to closest target. Uses filtering to prevent rapid changes in readings. Filter resets at 2% window.

The MB7985 Radio Bridge connector allows LoRaWAN connectivity for any HR series sensor with TTL ouput.

Connector Header Through Hole, Right Angle 7 position 0.100″ (2.54mm)

Connector Header Through Hole 7 position 0.100″ (2.54mm)

Connector Header Through Hole 7 position 0.100″ (2.54mm)

The MB8450 Car Detection Sensor is a low‑cost vehicle detection sensor that uses ultrasonic technology for non-contact sensing.
